FLUE GAS ANALYSIS SYSTEMS
Series "Como"
Filtration Systems
Continuous Flue Gas analysis systems in accordance with current legislation on air emissions for energy production facilities. Two models are available: Como 1 and 2. The first allows a measurement with records on paper. The second allows better accuracy and is equipped with a web interface for remote monitoring and analysis at ARPA.
Preconfigured analysis system, operation and size optimized for thermal power and/or electricity generating plants applications applied to district heating plants.
- Measurements: T, CO, CO2, NOX, O2, U, particulates.
- Accuracy: 0 to 2000 mg/m3.
- Max analyzed flows : 6.
- Certifications: CE / TÜV.
Range
Mod. Como
Flue gas analysis systems range
| POS. | Model | analyzed flows | Max Temp (°C) |
O2 Scale (%) |
O2 Scale (%) |
CO Scale (mg/m3) |
NOx Scale (mg/m3) |
particulates (mg/m3) |
humidity (%) |
precision (% f.s.) |
|---|---|---|---|---|---|---|---|---|---|---|
| 130 | Como 1 | 1÷6 | 450 | 0 - 20,9 | 0 - 15 | 0 - 2500 |
0 - 2700 (opzionale) |
0 - 999 (opzionale) |
0 - 100 (opzionale) |
±1 |
| 131 | Como2 | 1÷3 | 600 | 0 - 25 | 0 - 20 | 0 - 2000 | 0 - 2000 | 0 - 999 | 0 - 100 | ±0,1 |
Working condition
| HOT WATER | SUPERHEATED WATER | COOLING | |
|---|---|---|---|
|
THERMAL DESIGN DISCTRICT HEATING CIRCUIT |
90/65°C | 115/65°C | 7/11°C |
|
MECHANICAL DESIGN DISCTRICT HEATING CIRCUIT |
PN16÷PN25 | PN16÷PN25 | PN16÷PN25 |
|
THERMAL DESIGN SUBSTATIONS SECONDARY CIRCUIT |
85/55°C | 85/55°C | 14/8°C |
|
NOMINAL PRESSURE LOSS SUBSTATIONS PRIMARY AND SECONDARY CIRCUITS |
10/3 w.c.m. | 10/3 w.c.m. | 10/3 w.c.m. |
|
FLUID SPEED DISCTRICT HEATING CIRCUIT |
0,5÷2 m/s | 0,5÷2 m/s | 0,5÷2 m/s |
| CENTRAL CONDUIT PUMPS HEAD | 0,5÷9 bar | 0,5÷9 bar | 0,5÷9 bar |
| PRESSURE LOSS POWER PLANT INNER CIRCUIT | 0,5÷1,5 bar | 0,5÷1,5 bar | 0,5÷1,5 bar |
